280-8180-00
DXZ958RMC 33
Sound Adjustment
4. To change the details of the ADF setting,
press the [ADJ] button.
5. Touch
on the left of the display to
select the desired item.
Each touch of
switches the
adjustment item display as follows:
●Adjustment item (when USER is
selected in step 3)
BASS ➜ TREBLE ➜ COMP ➜ BASS...
●Adjustment item (when 1 to 3 is
selected in step 3)
LEVEL ➜ COMP ➜ LEVEL...
6. Touch
on the right of the display to
adjust the item.
∗ “BASS” and “TREBLE” can be adjusted
within the range 1 to 13.
∗ “LEVEL” can be adjusted within the range -
3 to +3.
∗ Select either “ON” or “OFF” for “COMP”.
7. Press the [SOUND] button to return to the
original mode.
SETTING items (only for 3
WAY and 2 WAY)
You can adjust the items listed in the SETTING
section only when you selected “3 WAY” or “2
WAY” in “SPEAKER SELECT”. The items you
can adjust are “P.EQ”, “X-OVER”, “TIME
ALIGN”, “SP GAIN”, and “ALL SEAT”.
SETTING–P.EQ
P.EQ (Parametric Equalizer) allows you to
compensate the entire frequency level range in
detail by smooth curve using frequency
compensation matched to the type of your car.
“P.EQ” can be adjusted only when the
“SPEAKER SELECT” is set to “3WAY” or
“2WAY” and “EQ SELECT“ is set to “P.EQ” (cf.
page 48).
• The factory default setting is “OFF”.
1. Press the [SOUND] button.
2. Touch [SETTING].
3. Touch [P.EQ].
SETTING
P.EQ X-OVER
TIME
ALIGN
SP
GAIN
ALL
SEAT
PRESET
RTN
OFF
4. Touch [ON/OFF].
The P.EQ effect is toggled ON/OFF.
P.EQ MODE
RTN
FREQUENCY
500Hz
1
L/R
BAND
LEFT
OFF
ON/OFF
5. Touch [L/R] to select “LEFT” or “RIGHT”.
6. Touch [BAND].
∗This item can be adjusted within the range
1 to 3.
7. Touch
on the left of the display to
select the item.
Each touch of
switches the
adjustment items as follows:
FREQUENCY ➜ Q ➜ GAIN ➜
FREQUENCY...
8. Touch
on the right of the display to
adjust the setting.
∗ “FREQUENCY” can be adjusted within the
range 20Hz to 20kHz.
∗ “Q” can be adjusted within the range of 1,
3, 5, 7 and 20.
∗ “GAIN” can be adjusted within the range
-12dB to +12dB.
9. Repeat steps 5 to 8 to adjust the each
setting.
∗ Touch and hold [L/R] for 2 seconds or
longer to copy the setting from one (left or
right) to the other.
10. When you have finished adjusting each item,
touch [RTN].
∗ You can store the settings. For details, see
“Storing and recalling the SETTING
adjustments” (page 36).
■ P.EQ adjustment
The settings that can be adjusted in the P.EQ
menu are as follows. The center frequency, gain
and Q curve can be stored to channel/band
combinations.
For example, center frequency “250Hz”, gain
“-8dB” and Q curve “3” can be stored to band 1
on the right channel.
LEFT/RIGHT (channel selection)
Selects the channel (left or right) to adjust.
BAND (band selection)
Selects the frequency band (1 to 3) to adjust.
Set the center frequency (FREQUENCY), gain
(GAIN) and Q curve (Q) for each frequency
band.
