7-8 SDC755A
7 • Maintenance
Maintaining the Moistener (DM400c Only)
Maintaining the Moistener
If you notice incomplete or poor sealing and the moistener tank is
full, you may need to clean the moistener brush or wick. If the seal
quality doesn’t improve after cleaning you can replace the stripper
blade and brush assembly or wick as needed. See Chapter 9,
Supplies and Options for instructions on ordering these supplies for
your machine.
Cleaning the Stripper Blade and Brush Assembly
1. Push the lever up, on the stripper blade and brush assembly.
2. Whilst holding the lever up, grasp the assembly and pull it
straight out towards you.
Stripper Blade &
Brush Assembly
Lever
3. Clean the moistener brush by running it under plain water.
NOTE: If the assembly cannot be cleaned throughly, then it
should be replaced.
4. If you need to clean the wick and shield, continue with Cleaning
the Shield and Wick
on the next page. Otherwise, push up on the
release lever on the stripper blade and brush assembly.
5. Slide the assembly back onto the machine. You should hear a
click as it engages.
