7-5SDC755A
7 • Maintenance
9. Close the ink access cover.
The system automatically
recognises the new cartridge
and in a few moments returns
you to the Home screen.
Refit the weighing platform if it
was removed previously.
8. Rotate the guard back to the closed position.
6. Remove the tape from the bottom of the new ink cartridge.
7. Lower the ink cartridge into the cavity. The ridges on either side
of the cartridge will slide into the grooves.
Groove
Ridge
Ridge
Replacing the Ink Cartridge/Printhead (continued)
