106
OPERATION
PROCEDURE
English
zChanging display mode
(1)
During
Single display in SD Mode, make sure that the OSD is not displayed, and then
press the [ ] button on the operating panel or the [AF ] button on the remote
control to change the display from Single display to 4x4 display.
(2)
Press the
[ ] and [ ] buttons on the operating panel or the [ ] and [ ] buttons on
the remote control to move the image selection cursor.
(3)
Press the
[ ] button on the operating panel or the [AF ] button on the remote
control to display the image selected with the image selection cursor in Single display.
Deleting, loc
king, and unlocking images
(1)
Make
sure that the OSD is not displayed, and then press the [ ] button on the
front panel or on the remote control. The output image changes to SD mode, and the
images stored on the SD card are displayed as single images. When you want to work
in 4x4 display, press the [ ] button on the operating panel or the [AF ] button on the
remote control to change to 4x4 display.
(2)
Use the
[ ] / [ ] buttons on the operating panel to select the image you want to
delete.
In Single display, the image you want to delete is displayed. In 4x4 display, use the
image selection cursor to select the image you want to delete.
(3)
Press the [MENU] button on the oper
ating panel to display the SD Mode OSD menu.
zDeleting images
From the OSD menu, select [SD] → [Delete].
To delete the image currently selected, select [Current]. To delete all images, select [All].
zLocking images
From the OSD menu, select [SD] → [Lock].
To lock the image currently selected, select [Current]. To lock all images, select [All].
zUnlocking images
From the OSD menu, select [SD] → [Unlock].
To unlock the image currently selected, select [Current]. To unlock all images, select [All].
