85
PART NAMES
AND
FUNCTIONS
English
Remote Control Reception
Point the transmission unit of the remote control at the sensor unit located on the front of the
camera main unit, press the operation button for the intended operation, and operate the camera
main unit accordingly.
Receivable Range
Distance: Within approx. 7m (23ft) from the front face of the remote control sensor unit.
Angle:
Within 30º up, down, left, and right from the r
emote control sensor unit.
within 7m (23ft)
30°
30°
30°
30°
30°
30°
30°
• The receivable range may be shortened or narrowed and the laser beam from the
remote control may not be sensed depending on the surrounding circumstances (e.g.,
sunlight, position adjacent to inverter fluorescent lamp). In this case, relocate the
receiving side or shield the sunlight or fluorescent lamp.
N o t e
