83
PART NAMES
AND
FUNCTIONS
English
List of functions
Name Function
(1) (POWER ON/OFF
standby status)
To turn the power ON/OFF. Only operates when the
main power switch is ON.
(2) SD mode/
highlight/
mask/scroll
operations
(Direction)
To move forward/backward through the images saved
in SD
mode.
M
oves the highlight section in highlight mode, moves
the mask section in mask mode, and moves the dis-
played image in scroll mode.
Moves the small screen during PIP.
To decide the OSD cursor for the recorder in Recorder
mode.
(3) ZOOM
(TELE)
To Zoom in.
P.113
(4)
(WIDE)
To Zoom out.
P.113
(5) (Highlight) To highlight part of the image displayed. *1
(6)
(Mask) To mask an area of the output image. *1
(7)
(Scroll) To enlarge the image currently displayed and move
up, down, left, and right. *1
(8)
(SD mode) To switch the output image to SD mode.
P.119
(9) (Capture) To save the image on the SD card.
P.105
(10)
Back To return the output image to camera image.
(11)
(Recorder) To operate an optional desktop recorder. *2
(12)
PIP
(Picture in Picture)
To display a still image as a small picture while dis-
playing a camera image.
(13)
(PC) To switch the output image to the image input to RGB
IN.
P.119
*1 This function can only be operated while displaying camera mode/SD mode.
(Cannot be used in conjunction with other functions.)
*2
Cannot be used when the desktop recor
der is not connected.
N o t e
