OPERATION
PROCEDURE
English
OPERATION PROCEDURE
4
Presentation Using Printed Materials, etc.
Setting the main unit
Set the main unit as shown in the figure above. Then connect it to a projector or a PC
monitor, and turn on the power for the main unit.
P.98
Lamp positioning
While watching the screen, adjust the angle of the lamp column and lamp head so that
light covers the stage evenly. Pointing the light emitting part of the lamp head straight down
allows the illumination to cover the stage evenly.
• Depending on the position of the lamp, the camera column’s shadow may fall across the
screen.
P.117
N o t e
Adjusting the size
Place an object on the stage and adjust the zoom dial on the front panel or the zoom
buttons [ / ] on the remote control so the part you want to shoot fits the screen size.
P.113
Adjusting the focus
In normal AF mode, the focus is automatically adjusted. In One-shot AF mode, the focus
is adjusted by pressing the [AF] button on the operating panel or on the remote control.
P.114
Adjusting the brightness
Press the [BRIGHTNESS ]/[BRIGHTNESS ] buttons on the front panel or on the
remote control to adjust the image brightness.
P.118
