MM-012099-001, Rev. B
91
If system selection is programmed to the Voice Group Selection control knob, direct
access to systems will not be available. Pressing or will scroll through
different sets of 16 systems each (banks) if more than 16 systems are programmed into
the radio. The systems within each bank are then selectable via the Voice Group
Selection control knob as described previously in METHOD 1.
Example:
System: 1 = North Group: 1 = Group 1
2 = South 2 = Group 2
3 = East 3 = Group 3
4 = West 4 = Group 4
1. Press
. (South is the currently selected system.)
2. Press
. (Press 4 to select “West” system.)
3. Press
. (West is the newly selected system.)
10.8.1 GROUP/CHANNEL SELECTION
Several methods can be used to select a new group or channel.
METHOD 1: From the Control knob: If group selection is programmed to the Voice Group Selection
control knob, select a group by turning the Voice Group Selection control knob to the
desired group number position. The display registers the new group name on line two.
If the knob is moved to a position greater than the number of programmed groups, the
highest programmed group will remain selected. The
button can be programmed to
provide access to a “2
nd
bank” of 16 group number positions (17-32).
METHOD 2: From keypad: If group selection is programmed as the primary function of
and ,
select a group by pressing or to scroll through the group list. The display
registers the new group name on line two.
METHOD 3: (P5470 model radios only) Direct Access: Press
to enter the group select mode.
Press the numeric key mapped to the desired group. Press
. The radio will move to
the selected group.
10.9 MODIFY SCAN LIST
10.9.1 P5470 Model
1. Press to toggle scan OFF and verify is not displayed.
2. Select group or channel.
3. Press
once to remove group from list.
4. Press
once to add as a normal group.
5. Press
twice to add as a Priority 2 group.
6. Press
three times to add as a Priority 1 group.
7. Press
to re-start scanning.
