MM-012099-001, Rev. B
74
An example of the backlight menu item selection process and menu item parameter change is shown in
Figure 9-9.
1. Press
to enter the menu mode.
2. Press
or until the display shows:
Figure 9-9: Backlight Menu Item Parameter
3. Press . The backlight menu item is activated. Line one shows the active menu item and its
current parameter setting. Line two shows the currently selected system or group name (see Figure
9-10).
Figure 9-10: Backlight Menu Display
4. The menu item's parameter setting shown in the display can now be changed by using
or .
5. Once the desired setting is reached press
to store the value and return the menu option selection
level.
For menu items that display radio information, pressing
or will scroll through a list of
informational displays. An example of information displays is shown in Table 9-4.
The TX POWER menu item, when selected, toggles LOW/HIGH power. It does not use
or to scroll nor is an additional press of the button required.
