MM-012099-001, Rev. B
53
Figure 8-11: Calls Received Lists
To access the Calls Received List, press the
key twice. Use the or buttons to scroll through
the list. Pressing the
key will display the time elapsed since the call was received. After pressing
the display will appear similar to Figure 8-12.
Figure 8-12: WHC Individual Call Display
Pressing the PTT will initiate an individual call to the displayed logical ID. Powering the radio OFF and
ON will clear this list.
8.22.2 Sending an Individual Call
8.22.2.1 Pre-Stored Individual Calls
The following procedures describe how to initiate and complete a Pre-Stored Individual Call.
P5470 Model Radio
1. To select a pre-stored individual phone number, enter the individual call mode using the
key. is
displayed. Then scroll through the list of stored numbers using the
or keys.
2. Press the PTT button; when the radio is clear to transmit,
turns ON, turns OFF and the channel
access tone sounds. Line one shows the called individual's name if found in the list of stored
individuals or LID followed by the logical ID number of the unit being called. The message *INDV*
displays on line two.
P5450 Model Radio
1. To select a pre-stored individual number, enter the menu mode by pressing the
key. Scroll
through the mode list using the
or buttons.
2. Press
. is displayed. Scroll through the list of stored phone numbers using the or
buttons until the desired number is displayed. Press .
