TASCAM DR-701D
19
Specifications
Ratings
8
Recording media
SD card (64 MB−2 GB)
SDHC card (4 GB−32 GB)
SDXC card (48 GB−128 GB)
8
Recording/playback formats
WAV: 44.1/48/96/192 kHz, 16/24-bit
BWF: 44.1/48/96/192 kHz, 16/24-bit
8
The number of input channels
4 maximum (44.1/48/96 kHz)
2 maximum (192 kHz)
8
The number of recording tracks
6 maximum (44.1/48/96 kHz)
2 maximum (192 kHz)
Inputs and outputs
8
IN 1/2/3/4 jacks (Phantom power supplied
only to XLR)
Connector: XLR-3-31, 6.3mm (1/4") standard TRS
jacks
8
EXT IN 1/2 jack (can provide plug-in power)
Connector: 3.5mm (1/8”) stereo mini jack
8
IN connector
Connector: 3.5mm (1/8”) stereo mini jack
8
PHONES jack
Connector: 3.5mm (1/8”) stereo mini jack
8
OUT connector
Connector: 3.5mm (1/8”) stereo mini jack
8
LINE OUT jack
Connector: 3.5mm (1/8”) stereo mini jack
8
HDMI IN/OUT connectors
Connector: Type A receptacle
8
USB port
Connector type: Micro-B
Format: USB 2.0 HIGH SPEED mass storage class
8
TIMECODE IN connector
Connector: BNC
8
REMOTE jack
Connector: 2.5mm (3/32") TRS jack
Audio performance
8
Frequency response
20 Hz – 20 kHz +0.5/−1 dB
(LINE IN to LINE OUT, 44.1/48kHz sampling
frequency, JEITA)
20 Hz – 40 kHz +0.5/−1 dB
(LINE IN to LINE OUT, 96kHz sampling frequency,
JEITA)
20 Hz – 80 kHz +0.5/−5 dB
(LINE IN to LINE OUT, 192 kHz sampling
frequency, JEITA)
8
Distortion
0.007% or less (MIC IN to LINE OUT,
44.1/48/96/192kHz sampling frequency, JEITA)
8
S/N ratio
100 dB or more (MIC IN to LINE OUT, −10 dBu
input, 1 kHz, 44.1/48/96/192kHz sampling
frequency, JEITA)
8
Equivalent input noise (EIN)
−124 dBu or lower
Note: based on JEITA CP-2150
Recording times (in hours: minutes)
File format (recording setting)
SDHC card
capacity
4 GB
WAV/BWF 16-bit (2 channels) 44.1 kHz 6:17
WAV/BWF 24-bit (2 channels) 96 kHz 1:55
WAV/BWF 24-bit (2 channels) 192 kHz 0:57
The recording times shown above are estimates.
They might differ depending on the SD/SDHC/
SDXC card in use.
The recording times shown above are not
continuous recording times, but rather they are
the total possible recording times for the SD/
SDHC/SDXC card.
If recorded in mono WAV format, the maximum
recording time will be double the figures above.
When using dual/4-channel recording in WAV/
BWF format, the maximum recording time will
be about half the figures above.
