10 Matrox G450 MMS – User Guide
Multi-display setup
To set up multi-display mode:
Windows 2000/XP –
If multi-display mode isn’t automatically enabled when you restart
Windows:
1
Right-click your Windows desktop background, then click
Properties
"
Settings
.
2
Select the disabled display, enable the
Extend my Windows desktop onto this monitor
check box, then click
Apply
.
3
To change resolution and color settings for each display, select a display, then change the
Screen area
and
Colors
settings. When you’re done, click
OK
.
Windows NT 4.0 –
1
Access the PowerDesk
Settings
property sheet (see “Accessing PowerDesk property
sheets”, page 8).
2
Click
Multi-Display Desktop
().
3
Move the
Desktop area
slider to adjust your multi-display desktop, then click
OK
to
accept your changes.
More PowerDesk information
For more information on Matrox PowerDesk:
Windows 2000/XP or NT 4.0 –
For context-sensitive help where available, click the “ ”
icon in the title bar, then click the item you want help on. Right-click a help topic for a
pop-up menu that lets you print or copy it. (Some help topics are only available through
context-sensitive help.)
Windows 2000/XP –
Access the PowerDesk
Information
property sheet (see “Accessing
PowerDesk property sheets”, page 8), then click
Help
or
View Readme File
.
Windows NT 4.0 –
!
Access the Matrox PowerDesk
Information
property sheet (see “Accessing PowerDesk
property sheets”, page 8).
!
Click the Matrox QuickDesk icon ( ) on your Windows taskbar, then click
Help
"
PowerDesk Guide
or
Help
"
View Readme File
.
Note:
In multi-display mode under Windows NT 4.0, the same display settings (resolution
and color palette) are used for each display.
