SCANTEAM 3400PDF User’s Guide
Example 1: Add Suffix for Specific Symbology
You want to send a CR (carriage return)ĂSuffix for UPC only.
Prefix and Suffix Examples
H Scan the Add Suffix Suffix Selection bar code.
H The Symbology Chart indicates that the Hexvalue of UPC is 63". Scan
6 and 3 on the Programming Chart on page 2-7.
H A CR" is equivalent to 0D" (see the Hex ASCII Chart). Scan 0 and D
on the Programming Chart.
H Scan the Save Current Suffix Changes Exit Selection bar code.
Example 2: Add Suffix for ALL Symbologies
You want to send a CR (carriage return)ĂSuffix for all symbologies.
H Scan the Add Suffix Suffix Selection bar code.
H The Symbology Chart indicates that the Hex value for All Symbologies
is 99". Scan 9 and 9 on the Programming Chart on page 2-7.
H A CR" is equivalent to 0D". Scan 0 and D on the Programming Chart.
H Scan the Save Current Suffix Changes Exit Selection bar code.
Example3: AddPrefix forSpecificSymbologyĂ/ĂSuffix forALL Symbologies
You want to send a HT (tab)ĂPrefix for UPC only and a CRĂ/ĂLF (carriage
returnĂ/Ăline feed) Suffix for all symbologies.
H Scan the Add Suffix Suffix Selection bar code.
H The Symbology Chart indicates that the Hex value for All Symbologies
is 99". Scan 9 and 9 on the Programming Chart.
H A CR" is equivalent to 0D" and an LF" is 0A". Scan 0, D, 0, and A
on the Programming Chart.
H Scanthe SaveCurrent PrefixĂ/ĂSuffixChangesExit Selectionbarcode.
H Scan the Add Prefix Prefix Selection bar code.
H The Symbology Chart indicates that the Hexvalue of UPC is 63". Scan
6 and 3 on the Programming Chart on page 2-7.
H An HT" is equivalent to09". Scan 0 and9 on the ProgrammingChart.
Example 4: To Clear a Specific Prefix Entry
You've programmed the scanner to send a CRĂ/ĂLF (carriage returnĂ/Ăline feed)
Prefix for all symbologies (Hex value, 99). This is one Prefix entry. You've also
programmed a #" Prefix for UPC (Hex, 63). You decide that you want to clear
the UPC entry, but not the Prefix entry for all symbologies.
H Scan the Clear Specific Prefix Prefix Selection bar code.
H The Symbology Chartindicates thattheHex valuefor UPCis 63". Scan
6 and 3 on the Programming Chart on page 2-7.
