1–7
SCANTEAM 3400PDF User’s Guide
IBM PC AT and Compatibles Interface
IBM PC Interface
IBM PS/2 and Compatibles Interface
These bar codesalso program a carriagereturn (CR) suffix.
(also PS/2 30Ć286, 50, 55SX, 60, 70, 70Ć061, 70Ć121, 80)
(Terminal ID 03)
(for PS/2 25, 30 models)
(Terminal ID 02)
RSĆ232 Interface
(Terminal ID 00)
Baud Rate 9600 bits per second
Parity even
Data Format 7 data bits, parity bit, 1 stop bit
(8 Bit Data)
The bar code above also programs the following parameters:
Programmable Option Setting
RS–232 Interface
Indicates default selection.
