6-14 SDC755A
6 • System Options
Selecting Tone/Pulse
Use this to tell the system whether your exchange requires tone or
pulse dialling.
NOTE: In the UK and ROI almost all exchanges are now
equipped to handle tone dialling.
1. Press Options.
2. Press Page Down if necessary.
3. Select "Data Centre Options".
4. Select "Phone Settings".
5. Select "Dial Type".
6. The display toggles between Tone or Pulse, select whichever is
appropriate.
7. Press Home to return to the home screen.
Phone Settings
This menu option allows you to modify the phone connection settings
on your machine (dial prefix, etc.)
Entering the Dial Prefix
Use this if you need to dial a prefix number (like 9) to get an outside
line.
1. Press Options.
2. Press Page Down if necessary.
3. Select "Data Centre Options".
4. Select "Phone Settings".
5. Select "Dialling Prefix".
6. Key in the prefix number you want (such as a "9"). If you do not
require a prefix number, select "No Prefix Required".
NOTE: You can use the decimal point (.) to insert a pause
after the dial prefix, if required by your exchange.
7. Select "OK". You return to the Phone Settings menu.
8. Press Home to return to the home screen.
