MM23772, Rev. F
34
MENU
NAME
RADIO
DISPLAYS
USAGE NOTES
See Previous Page
Selected
Channel
“ChannelMenu”
Displays the current channel. Press to return to dwell display.
Scan Mode
“ScnModeMenu”
Use or to scroll through available scan modes (Normal, No Scan, or Fixed).
Press
to return to dwell display.
Talk group
Lock Out
“LockOutMenu”
Use
or to choose a talk group for locking/unlocking. Press to toggle “<” on
(locked out) and off.
Priority 2
Talk group
“Priority2”
Use
or to choose Priority 2 talk group. Press to return to dwell display.
Priority 1
Talk group
“Priority1”
Use
or to choose Priority 1 talk group. Press to return to dwell display.
Alerts Received
“Alerts Rcvd”
or oldest message
“No alerts” or alert message text scrolls in display. Use
or to scroll through all
messages.
Alert Destination
“Alert Dest”
Use
or to choose a speed-dial number. Press to go to the “Alert Msg” menu.
Use
or to scroll through “canned messages.” Press to send message and
return to dwell display.
Speed Dial
“Speed Dial”
Use
or to choose a speed-dial number and press PTT to place call.
Profile Selection
“ProfileMenu”
Use
or to choose an available profile. Press to return to dwell display.
Talk group
Selection
“TalkGrpMenu”
Use
or to choose a talk group in current profile. Press to return to dwell
display.
Status LED
“Status LED”
Use or to toggle status led “On” or “Off.” When On, the LED flashes red when
the radio transmits, green when receiving, and amber when in emergency. When Off,
the LED will not light at all.
VTAC Client
Mode
“Client Mode”
Use or to choose Client Mode (Network, XCOV, XCOV-TG, or SOI).
Emergency
Dismiss
“EmgDismiss”
Use
or to choose emergency talk group. Press to toggle “<” on (dismiss) and
off.
Use and to scroll through menus.
