MM23772, Rev. F
115
Table 11-5: Menu Item Information
FEATURE DISPLAY
PARAMETER
SETTING
COMMENT
Keypad Lock
Menu Item:
KEY LOCK
Once Selected:
LOCKED
Locked
Unlocked
Locks the keypad. To unlock; press and release “M” then
within 1 second press the option button (NOTE: this
sequence is also a short cut to locking the keypad.)
Backlight Adjust
Menu Item:
BCK LIGHT
Once Selected:
BCKL=
OFF/ON Selects the light level for backlighting.
Contrast Adjust
Menu Item:
CONTRAST
Once Selected:
CNTRST=
1, 2, 3, 4 Selects the display contrast level.
Transmit Power
Select
Menu Item:
TX POWER
Once Selected:
POWER=
HIGH or LOW Selects radio output power mode.
Radio Revision
Information
Menu Item:
REVISION
N/A
Selects the information display to view. Informational
display only (see Table 11-6). No user sel
ectable settings.
Toggle Scan
On/Off
SCAN ON/OFF Toggles Scan operation ON/OFF.
Display Current
Home Channel
HOME N/A Selects Home Channel.
Select Desired
System
SYS SEL N/A Selects a new system.
Add Channel to
Scan List
SCAN ADD N/A Adds to Scan List.
Delete Channel SCAN DEL N/A Deletes Channel from Scan List.
Add/Delete Scan
List
SCAN A/D N/A Add or Delete from Scan List.
Talkaround TALKARND ON/OFF Toggles Talkaround feature ON/OFF.
Select Channel CHN SEL N/A Conventional Only.
Feature
Encryption
Display
Menu Item:
FEATURES
Once Selected:
(See Feature
Encryption Display
Section)
N/A
Indicates current features programmed into the radio as
well as certain information required to add features to the
radio. Informational display only. No user selectable
settings.
