MM101332V1, Rev. K
11.1.3 Deleting Groups from a Scan List
11.1.3.1 Scan Model
1. With scan operation turned OFF, select the desired group to delete from the selected trunked system
group scan list.
2. Press
. The current status of the group is displayed for a time-out period.
While the current status is displayed, press
. until the group from the scan list is "blank". The
sequence is "blank",
, , ,"blank". Any group that is not in a trunked system group scan list will
show a "blank" for the time-out period when it is the selected channel.
11.1.3.2 System Model
1. With scan operation turned OFF, select the desired group to delete from the selected trunked system's
group scan list.
2. Press
. The current status of the group is displayed for a time-out period.
While the status is displayed, press
to delete the group from the scan list. , ,or turns OFF. Any
group that is not in a trunked system group scan list will show a "blank" for the time out period when it is
the selected channel.
11.1.3.3 Nuisance Delete
A group can also be deleted from the scan list, if it is not the currently selected group, by pressing the
key (Scan model) or the
key (System model) during scan operation while the radio is displaying the
unwanted group. The group will be deleted from the system's group scan list in the same manner as if
done using the steps above. Deletions done in this manner will not remain deleted if the radio is powered
OFF and then powered ON.
11.2 SCANNING TRUNKED SYSTEMS
The radio can be programmed with the following System Scan features. These features are automatically
enabled when the radio is powered ON. A key or menu option is also defined to allow the System Scan
features to be toggled during radio operation. This is covered in the Menu Selection and Pre-Programmed
Keypad Key sections. The System Scan state will be maintained through system changes but will default
to ON when the radio is powered ON.
11.2.1 Wide Area System Scanning
The P7100
IP
series radios can be programmed for Wide Area System Scan operation for roaming across
mobile systems. Upon the loss of the currently selected system's control channel, radios can be
programmed to automatically scan the control channels of other systems. If a new control channel is
found, the radio will switch to the new system and sound an alert tone.
43
