MM101332V1, Rev. K
MESSAGE NAME DESCRIPTION
SYSC OFF System Scan
Features Off
Trunked mode only. Indicates the System Scan
features are disabled.
LOW BATT Low Battery Battery voltage has dropped to the point to where the
radio is no longer able to transmit. The radio will still
receive calls until the battery is discharged beyond
the point of operation at which time the radio will
automatically shutdown.
Trunked and P25 modes only. Indicates an
emergency call is being received. This message will
be flashing on line two.
Receive
Emergency
RXEMER
Trunked and P25 modes only. Indicates an
emergency call has been transmitted on this radio.
This message will be flashing on line two.
Transmit
Emergency
TXEMER
Volume Level Indicates the current volume level. The volume level
display ranges from OFF (silent) to 31 (loudest).
VOL=31
WHC Who Has
Called
Trunked and P25 modes only. Indicates an
individual call has been received, but not responded
to. The indicator turns OFF if the individual call mode
is entered, the system is changed, or the radio is
turned off and then on again.
UNKNOWN Unknown ID
Trunked and P25 modes only. Indicates an
individual call is being received from an unknown ID.
8.2.4 Error Messages
If either of the Error Messages shown below is displayed, the radio is programmed incorrectly or needs
servicing.
DSP ERR
ERR=XXXX
(PowerUp only)
or
DIG V x
ERR x
Where: xxxx is the error code and DSP ERR or DIG V ERR is the message.
8.3 ALERT TONES
The P7100
IP
radio provides audible Alert Tones or “beeps” to indicate the various operating conditions
(see
Table 8-2).
27
