MM101332V1, Rev. K
10.12.3 Private Mode
The Private Mode allows the radio to transmit encrypted messages and receive clear or private
transmissions. The radio transmits private if the group/channel is programmed for private operation and
forced operation is pre-programmed. If autoselect operation is pre-programmed and the radio is in the
Private Mode, the radio transmits in the mode of the received call if the hang time is active. If no hang
time is active, the radio transmits private.
Cryptographic keys are transferred to the radio using a cryptographic Keyloader. Up to seven (7) different
cryptographic keys, numbered 1-7, can be transferred from a Keyloader and stored in the radio. An
individual key is automatically selected on a per-group/channel basis according to the radio programming.
Groups and channels within the digital system can be programmed for keys 1-7 (private). Up to 8 banks
of 7 keys can be stored for private systems. The bank is specified per system.
When operating on a group or channel programmed for Private Mode, all transmissions are private
transmissions and the radio receives clear and private signals. The status icon
is displayed when the
Private Mode is enabled. If the selected group or channel is programmed for auto-select capability, the
mode may be toggled between private and clear with the
key, then following the selection mode rules.
Radios programmed for forced private operation do not allow a change of the transmit mode.
10.12.3.1 Displaying the Currently Used Cryptographic Key Number
To Display the Currently Used Cryptographic Key Number for either the system encryption key (for
special call such as individual, phone, all, agency or fleet) or the group/channel key (for group or
conventional calls), perform the following procedure:
1. Press the
button.
2. Use the
or button to select "DISP KEY."
3. Then use the
or button to toggle between displaying the system key or the group/channel
key.
10.12.3.1.1 System Encryption Key
Figure 10-4: System Encryption Key Display
10.12.3.1.2 Group/Channel Encryption Key
Figure 10-5: Group/Channel Encryption Key Display
