MM101332V1, Rev. K
5.4 CHANGING THE BATTERY PACK
5.4.1 Removing the Battery Pack
Make sure the power to the radio is turned OFF.
1. Press the latch at the bottom of the battery pack.
2. Lift the battery pack from the bottom.
3. Remove the battery pack from the radio.
Figure 5-1: Removing the Battery Pack
5.4.2 Attaching the Battery Pack
Make sure the power to the radio is turned OFF.
1. Align the tab on the top of the battery pack with the slot at the top of the battery cavity.
2. Push the battery pack down to attach the battery to the radio.
3. Verify that the battery pack is properly latched to the radio.
Figure 5-2: Attaching the Battery Pack
14
