PC Mode
PC Mode (Other)
HDD SAFETY Switch Operation
When using a USB connection, place the unit device on a flat, level surface. If the
HDD SAFETY switch is activated, carry out the following remedies.
●●
●●
● For Windows 98SE/Me
If the HDD SAFETY Detection Switch is activated while a PC Card HDD is being
accessed, the PC screen goes blue and the following message appears.
a “SAFETY MODE PUT IT DOWN” appears on the unit LCD. Make sure that the
unit is always placed on a flat, level surface.
b When the unit LCD changes to “SD” or “HDD” selection screen, and the HDD Lamp
starts flashing, press [Enter].
• The PC screen will turn black momentarily and the unit will then continue the
operation that was in progress before the switch was activated. Wait for a short
period while the HDD Lamp flashes. If the HDD Lamp stays off and the PC
screen does not return to its previous state, press [Enter] once more. If this has
no effect, disconnect the USB cable and restart the computer.
• After processing is complete, check that the required operation has completed
normally. Repeat the operation if necessary.
●●
●●
● For Windows 2000/XP
If the HDD SAFETY Detection Switch is activated while the PC Card HDD is being
accessed in PC mode, the following message may appear.
[ For Windows 2000 ] [ For Windows XP ]
Place the unit on a flat, level surface, and then click [OK], [Cancel], [Try Again]
or [Continue].
• Processing will be interrupted, so repeat the operation.
• If the HDD SAFETY switch was activated while the PC Card HDD was being accessed, it is
advisable to run ScanDisk/CheckDisk on the computer. (p. 9)
– Note –
Error Reading Disk in Drive**:
Please Insert Disk ***
With Serial Number *** in Drive *:
Press ENTER for OK or ESC to Cancel : OK
