Panasonic SV-PT1PP Portable Media Storage User Manual



26
TV Mode (Display Information)
M
C
A
N
C
E
L
E
N
U
/SET
MENU
SET
Displayable Image Formats
JPEG files altered and saved on a PC as grayscale
format cannot be displayed.
Some parts of an image may not be displayed or the
image may be displayed on a smaller scale depending
on the size of the image.
Note
Images of the following formats can be displayed.
DCF format 1.1 compliant
Baseline JPEG format Y Cb Cr (compressed
format)
(Sampling ratios 4:4:4, 4:2:0, 4:2:2, 4:1:1)
(80 x 60 ~ 5120 x 3840 pixels)
TIFF format RGB (RGB 8 bit non-compressed)
(This image format takes longer to be displayed.)
The first image from Motion JPEG (QuickTime
format) files with a mov extension
Folders and Files
Folders and files that are displayed in the Index Area (p. 25) are described in the table
below. Refer to page 10 for details on the folder structure.
File and folder names will not be displayed correctly if...
more than 8 characters are used.
spaces and special symbols are used. Use care when changing file and/or folder names.
Note
Folder
JPEG File
TIFF File
MOV File
Protect
Blue
Pink
Gray
Folder contains displayable images.
Folder contains presentation files (PRES_***).
Folder contains no displayable images.
TIFF files take longer to be displayed in full screen and
Slide Show. In some cases, only TIFF icons appear in index
or album displays. Some files may not be displayed, or may
be displayed on a smaller scale.
These are files with moving images or still images with
audio content. Only the first frame of a moving image is
displayed. Rotated images cannot be saved.
Protected folders and files (p. 36) cannot be deleted.
TIFF
PT1.p24-28.p65 2003/01/14, 12:3626
