Before Use
Inserting the Card
SD Memory Card Slot
1 Push up slightly on card
door to swing open.
2 Insert the Memory Card
(labeled side up, cropped
corner right) and hold in
place until you hear a click.
3 Close the lid.
To remove Card :
Open card door.
Press in lightly on
card then release.
cropped corner
PC Card Slot
1 Slide the lever to open the
cover.
2 Insert the PC Card HDD or
PC Card all the way into
the slot.
3 Close the cover.
To remove Card :
Press EJECT TAB
twice.
• Always insert card in the correct direction. Failure to do so may result in damage to the card
and this unit.
• The PC Card HDD and Memory Card are precision devices. Do not subject them to excessive
pressure or strong impacts.
• If the card door does not close completely, remove the card, check insertion orientation, and
reinsert. Also, confirm that EJECT TAB was firmly pressed.
Set STANDBY to OFF when inserting or removing a Card.
2
1
Caution
