19
Copy Mode
Copy Mode (Display Indicator)
Liquid Crystal
Display
– Note –
• Any cards that utilize adaptors other than the accessory PC Card HDD adaptor are displayed
as “PC CARD”.
M
C
A
N
C
E
L
E
N
U
/SET
Displaying Menu (Indicator Flowchart)
MENU
STANDBY/SET
COPY T
V
MODE
COPY/TV
MODE
1 Set COPY/TV MODE to “COPY”.
2 Insert a Card. (p. 17)
3 Turn on this unit. (p. 18)
In Copy mode, data can be copied from one
card to another. You can also check card
storage capacity, make backups, set TV
formats, and format cards.
If unit is on battery power only, power shuts off
automatically if you perform no operation for
5 minutes to conserve battery.
POWER Lamp
When using battery When using AC adaptor
(When a PC Card
HDD is inserted)
Press SET
If a button is not pressed
within 10 seconds.
Press MENU
*
*
“Copying” (p. 21)
“Menus” (p. 20)
* When HDD SAFETY is
ON and is activated
(p. 18), the PC Card HDD
cannot be verified, so
always place unit on flat,
level surface.
(When an SD Memory
Card is inserted)
(When a PC Card and SD
Memory Card are inserted)
(When a PC Card
is inserted)
Follow these steps to display menus in COPY mode.
