IMAGETEAM 3800 User’s Guide
5–2
Other Programming Selections
D Clear One Data Format
This deletes one data format for one symbology. If you are clearing the
primary format, scan 0. If you are clearing an alternate format, scan 1,
2, or 3, depending on the alternate format you are clearing. Scan the
Terminal Type (refer to the Supported Terminals Chart on page 2–3),
Code I.D. and the length of the format you want to delete. That length
data format for that symbology is deleted and all other formats are
unaffected.
D Save
This exits, saving any Data Format changes.
D Discard
This exits without saving any Data Format changes.
Data Format Editor Commands
Send Commands
F1 Send all characters followed by “xx” key or function code, starting from current
cursor position. Syntax = F1xx (xx stands for the hex value for an ASCII code,
see Decimal to Hex to ASCII Conversion chart, page 4–5.)
F2 Send “nn” characters followed by “xx” key or function code, starting from
current cursor position. Syntax = F2nnxx (nn stands for the numeric value
(00-99) for the number of characters and xx stands for the hex value for an
ASCII code. See Decimal to Hex to ASCII Conversion chart, page 4–5.)
F3 Send up to but not including “ss” character (Search and Send) starting from
current cursor position, leaving cursor pointing to “ss” character followed by
“xx” key or function code. Syntax = F3ssxx (ss and xx both stand for the hex
values for ASCII codes, see Decimal to Hex to ASCII Conversion chart, page
4–5.)
F4 Send “xx” character “nn” times (Insert) leaving cursor in current cursor
position. Syntax = F4xxnn (xx stands for the hex value for an ASCII code,
see Decimal to Hex to ASCII Conversion chart, page 4–5, and nn is the
numeric value (00-99) for the number of times it should be sent.)
E9 Send all but the last “nn” characters, starting from the current cursor position.
Syntax = E9nn (nn is the numeric value (00-99) for the number of characters
that will not be sent at the end of the message.)
Move Commands
F5 Move the cursor ahead “nn” characters from current cursor position.
Syntax = F5nn (nn stands for the numeric value (00-99) for the number of
characters the cursor should be moved ahead.)
F6 Move the cursor back “nn” characters from current cursor position.
Syntax = F6nn (nn stands for the numeric value (00-99) for the number of
characters the cursor should be moved back.)
F7 Move the cursor to the beginning of the data string. Syntax = F7.
EA Move the cursor to the end of the data string. Syntax = EA
