2–
IMAGETEAM 3800 User’s Guide
Supported Terminals Chart
Terminal Model(s) Terminal ID
Apple Mac Mac Classic, SE SE30, II (All) 049**
Apple Mac Powerbook 5300 Series (Portable PC) 049**
DEC VT510, 520, 525 (PC style) 005
DEC VT510, 520, 525 (DEC style LK411) 104
Esprit 200, 400 005
Heath Zenith PC, AT 090
HP Vectra 003
HP Vectra AT 023
IBM XT 001
IBM PS/2 25, 30, 77DX2 002
IBM AT, PS/2 30–286, 50, 55SX,
60, 70, 70–061, 70–121, 80 003*
IBM 102 key 3161,3162, 3163, 3191, 3192, 006
3194, 3196, 3197, 3471, 3472,
3476, 3477
IBM 122 key 3191, 3192, 3471, 3472 007
IBM 122 key 3196, 3197, 3476, 3477 008
3486, 3482, 3488
IBM 122 key 3180 024
IBM 122 key 3180 data entry keyboard 114
IBM DOS/V 106 key PC & Workstation 102
IBM Thinkpad 360 CSE, 340, 750 097
IBM Thinkpad 106
IBM Thinkpad 365, 755CV 003
I/O 122 key 2676D, 2677C, 2677D 008
ITT 9271 007
Lee Data IIS 007
NEC 98XX Series 103
Olivetti M19, M200 001
Olivetti M240, M250, M290, M380, P500 003
RS232 TTL 000
Serial Wedge 050
Silicon Graphics Indy, IndigoII 005
* = Default
** = Applies to all –12 models only.
