IMAGETEAM 3800 Users Guide
IBM 4683 Ports 5B, 9B, and 17 Interface
Note: The following Retail “Plug and Play” codes are for use with the
3800LR–11 model only.
Scan one of the following Plug and Play codes to program the IT3800 for IBM
4683 Port 5B, 9B, or 17.
Note: After you scan one of the codes, power cycle the cash register to have
the interface in effect
IBM 4683 Port 5B Interface
IBM 4683 Port 9B HHBCR-1 Interface
IBM 4683 Port 9B HHBCR-2 Interface
IBM 4683 Port 17 Interface
Each bar code above also programs the following suffixes for each symbology:
Symbology
Suffix Symbology Suffix
EAN 8 0C Code 39 00 0A 0B
EAN 13 16 I 2 OF 5 00 0D 0B
UPC A 0D Code 128 00 18 0B
UPC E 0A
