Section 13 Specifications
13–1
IMAGETEAM 3800 User’s Guide
Product Specifications
Dimensions
Height 6.0 inches (15.2 cm). . . . . . . . . . . . . . . . .
Length 5.3 inches (13.5 cm). . . . . . . . . . . . . . . . .
Weight 6.3 ounces ( 179.2 g). . . . . . . . . . . . . . . . .
Width 3.1 inches ( 7.9 cm). . . . . . . . . . . . . . . . . .
Light Source 630 nm visible red LED. . . . . . . . . . . .
Scan Rate Programmable to 270 scans per second. . . . . . . . . . . . . .
Skew Angle ±30 degrees. . . . . . . . . . . . .
Pitch Angle ±15 degrees. . . . . . . . . . . . .
Horizontal Velocity 5 inches (12.7 cm) per second. . . . . .
Minimum Reflectance
Difference 30% – LR/HD, 40% – PDF. . . . . . . . . . . . . .
Decode Rate 270 decodes per second. . . . . . . . . . . .
Power Requirements 5VDC ±10% at scanner. . . .
Current Draw (–12 models)
@270 s/s 275 mA Scanning; 125 mA Standby;. . . . . . . . . . . . . . .
5 microA Low Power; 300 mA In-Rush
Temperature Ranges
Operating 32° F to +122° F (0° C to +50° C). . . . . . . . . . . . . .
Storage –40° F to +140° F (–36° C to +60° C). . . . . . . . . . . . . . . .
Humidity 0 to 95% non-condensing. . . . . . . . . . . . . . .
Mechanical Shock Operational after 25 drops from 5 feet . . . . . . .
(1.53 m) to concrete
Vibration Withstands 5G peak from 20 to 300 Hz. . . . . . . . . . . . . . .
ESD Sensitivity 15 kV to any external surface. . . . . . . . .
Agency Compliance FCC Class B, CE EMC Class B, CE Low. . . . .
Voltage Directive, EN60825–1,
IEC60825-1 LED Safety: Class 1, UL, cUL,
TÜV Certified to EN60950, C–Tic.
