La Crosse Technology WS-7138U Portable Radio User Manual



21
Do not submerge in water.
Immediately remove all low powered batteries to avoid leakage and
damage.
Opening the casings invalidates the warranty. Do not try to repair the unit.
Contact La Crosse Technology for repairs.
SPECIFICATIONS
Temperature measuring range:
Indoor:
14.2°F to 122.0°F with 0.2°F resolution
(-9.9°C to 50.0°C with 0.1°C resolution)
“OFL” displayed if outside this range
Outdoor:
-21.8°F to 157.8°F with 0.1°F resolution (-
29.9°C to 69.9°C with 0.1°C resolution)
“OFL” displayed if outside this range
Relative humidity measuring range:
(Indoor and Outdoor)
1% to 99% with 1% resolution
“- -” displayed if outside this range
Indoor temperature checking interval: Every 10 seconds
Indoor humidity checking interval: Every 10 seconds
Outdoor temperature and humidity
checking interval (remote
temperature/humidity sensor):
Every 1 minute
Outdoor Temperature and humidity
reception (indoor weather station):
Every 5 minutes
Transmission Range: 80 feet (in open space)
Power Supply:
Indoor weather station: 2 x AAA, IEC LR6, 1.5V.
Remote temperature/humidity sensor: 2 x AA, IEC LR3, 1.5V
Battery life cycle: Approximately 12 months
Recommended battery type: Alkaline
Dimensions (H x W x D)
Indoor weather station (without stand):
4.13 x 3.54 x 0.84
(105 x 90 x 21.5 mm)
Remote temperature/humidity sensor:
(excluding wall bracket)
6.3” x 2.95” x 2.2”
(160 x 75 x 55mm)
