11
11. Press and release the IN/OUT, SET/CH button to confirm the
settings and exit the setting mode.
FEATURES OF THE WS-7138U
I. INDOOR TEMPERATURE, HUMIDITY, AND COMFORT LEVEL
INDICATOR
• The current indoor temperature (viewed on the left) and relative
humidity (viewed on the right) is displayed in the
TEMPERATURE/HUMIDITY portion of the LCD.
o The current indoor humidity is also displayed in the bar graph
at the top of the LCD.
• The comfort level indicator is located at the center of the
TEMPERATURE/HUMIDITY display.
o The indicator will display a happy face icon when the
temperature is between 68°F and 79°F (20°C and 25.9°C), and
the humidity is between 45% and 65%.
o A sad face icon will be displayed when the temperature and
humidity are outside the mentioned ranges.
Indoor
Readings
Indicato
r
Outdoor Readings
Comfort
Remote Temp/Humidity
Sensor Channel Indicato
r
Remote
Sensor
Reception
Icon
Humidity Level Bar Graph
Minimum Readings
Maximum Readings
