© 2005 Directed Electronics—all rights reserved
System Wiring Diagram Example
NOTE: The Second Power cable must be connected or the unit will not operate and
will cause damage to the unit.
Video In
VCR
or
AUDIO AMPLIFIER
OUT
Power
ININ
Audio
R
Video
L
Audio
Video
DVD
or
TV Tuner
DVD
L
R
BLACK (GROUND)
GRAY (DOOR SWITCH)
YELLOW
+12V CONSTANT
IR Transmitter
BLACK (GROUND)
RED (ACC)
YELLOW
BATTERY (+12V)
POWER CABLE
SECONDARY POWER CABLE
DOME LIGHT CABLE
DIN CABLE
38
