© 2005 Directed Electronics—all rights reserved
DVD—UNMOUNTED
The illustration below shows the side of the DVD player when removed from the LCD monitor.
1. Electrical connector—This connector provides the electrical interface when mounted in the LCD
monitor.
2. VOL Control—Controls the volume to the phone jack output.
3. PHONE Jack—An optional headphone set can be connected here.
4. A/V OUT Jack—Audio/video output jack.
5. DC 12V Jack—Input power.
6. IR Receiver—For receiving commands from the remote control.
VOL PHONE A/V OUT
DC 12V
12345 6
12
