LCD Display / Summary of States by LED Lights
The battery level icon indicates how much battery life is left. The number of segments in
the icon becomes less as the battery discharges. For some batteries or re-chargeable dry
cells, the number of segments in the battery icon may increase or decrease irregularly
when the remaining charge is being measured. This is normal.
When the battery runs out, the battery icon starts blinking. If this happens, connect the
AC Power Adapter to re-charge the battery. If you don’t have the AC Power Adapter,
"safety power off".
When an ID3V2 or ID3V1 tag is used, the disk icon and the Artist + Album information
are displayed. When the display setting is ‘Filename’, or the tag does not include the
Artist information, the folder icon and the folder name are displayed. When the song is
contained in the root folder, "iAUDIO" is displayed in the folder name.
Mode
Play Status
Battery Level
Current Track /Total Tracks
Singer Name, Album Title
Song Title
Progress Bar
Play Time
BIT RATE
SAMPLING RATE
JetEffect (BBE,M3B,3D,MP)
5 Band EQ
Block Repeat
Hold (Body, Remote Controller)
Play Sequence
Summary of States by LED Lights
HDD LED
Lights up GREEN when HDD starts
MODE LED
DIGITAL AUDIO Mode: Blue
FM RADIO Mode: Green
VOICE RECORDER, LINE IN RECORDER Mode: Orange
CHARGE Mode: Bluish Green when fully charged
CHARGE LED
Lights up RED while the battery is being re-charged, and goes off when it is fully charged
Total Time
LCD Display
