Control Panel Menus
Control Panel Menus
The control panel’s menu system is a hierarchy of menus, menu items, and menu item
values. The menus are used to configure the printer for your environment.
The control panel provides access to the following menus:
■ Job Menu — see page 10
■ Password Menu
1
— see page 10
■ Tray Menu — see page 11
■ PCL Menu — see page 16
■ System Menu — see page 18
■ Parallel Menu — see page 21
■ Serial Menu
2
— see page 22
■ USB Menu — see page 24
■ Ethernet Menu
3
— see page 24
■ Token Ring Menu
4
— see page 27
■ Novell Menu — see page 30
■ Print Menu — see page 33
■ Reset Menu
5
— see page 34
Press either the Menu key (labeled 1 or 5) to access the menus.
Using the control panel menus
1. Press the Menu keys (labeled 1 or 5) to scroll through the available menus until you
locate the one you want.
The following sample control panel screen shows the System Menu.
2. Press the Item keys (labeled 2 or 6) to scroll through the menu items. (If you are in the
Password Menu, you must first press either Item key to access the password prompt
and type the password using the control panel keys.)
1. Appears only when the Hard Drive is installed.
2. Appears only when the Serial Interface option is installed.
3. Does not appear when the Token Ring Card is installed.
4. Appears only when the Token Ring Card is installed.
5. Appears only when Reset Mode is enabled. (The On Line and Enter keys are held down simultaneously at Power On.)
Menus
System Menu
