91FTM-10R OPERATING MANUAL
MENU
(
“SET”
)
MODE
ÚÚ
ÚÚ
Ú
:
Depends on the band of operation.
SWITCH/KNOB SETTING
Enables/Disables the beeper.
Selects the category which is recalled from the top panel
/ key.
Assigns a function to the Function Key.
Select the function of the microphone’s [PGM] key.
Enables/Disables the locking of the PTT key when the LOCK mode is
activated.
Selects the PTT key function.
Setting of the synthesizer steps.
WiRES SETTING
Enable/Disable the Internet Connection feature.
MISCELLANEOUS SETTING
Enables/Disables the Automatic Audio Volume Controller.
Enables/Disables the AF DUAL operation.
Select the Tone Pitch control for the received audio.
Enable/Disable the Volume Setting Alert feature.
Select the DIAL knob and display function.
Enables/Disables the band expansion.
Shifting of the CPU clock frequency.
Selects the receiving mode.
Set the squelch threshold level.
SET MODE ITEM
6 BEEP
14 FKEY MOD
15 FKEY SEL
20 MIC PRGM
22 PTT LOCK
23 PTT MODE
41 STEP
SET MODE ITEM
48 WIRES
SET MODE ITEM
1 AF AUTO
2 AF DUAL
3 AF PITCH
4 AF PREST
5 AF-VFO
27 RX EXP
28 RX F CCL
29 RX M MOD
38 SQL LEVEL
AVAILABLE VALUES
(
DEFAULT
)
KEY+SC/KEY/OFF
FNC/FNC+MSG/MSG
AF DUAL, ARTS, DIMMER, HORN
1, HORN 2, HORN 3, HORN 4, IN-
TERCOM, MONI, PA, REVERSE,
SCAN, SQL LEVL, SSCH, TCALL,
TX POWER, VOL.ITCOM
TX LOW/RPTR/SQLTYP/REV/
TSQLF/DCODE/MONI/TCALL/
SSCH/ARTS/TAG/MHz/SCAN/
CLUB/WX
OFF/ON
MOMENT/TOGGLE
5.00/6.25/8.33/10.00/12.50/15.00/
20.00/25.00/50.00/100.00/200.00
kHz, or AUTO
AVAILABLE VALUES
(
DEFAULT
)
OFF/CODE/MEM
AVAILABLE VALUES
(
DEFAULT
)
OFF/ON MIN/ON MID/ON MAX
OFF/ AM AUTO / AM HOLD/ FM
AUTO/ FM HOLD/ LI AUTO / LI
HOLD
LOW-3/LOW-2/LOW-1/NORMAL/
HIGH-1/HIGH-2
OFF/OV ALERT/LV ALERT/ HV
ALERT
TOGGLE/AUTOBACK
NORMAL/EXPAND
OFF/ON
AUTO/WIDE FM/FMNARR FM/
AM
SQL OFF/SQL MIN/SQL 01/SQL
02/ SQL 03/ SQL 04/ SQL 05/ SQL
06/ SQL MAX
Amateur Bands: SQL 01
AM: SQL 01, FM: SQL 02
