98 FTM-10R OPERATING MANUAL
MENU
(
“SET”
)
MODE
Set Mode Item [
F34 SPEAKERF34 SPEAKER
F34 SPEAKERF34 SPEAKER
F34 SPEAKER]
Function: Select the Speaker to be used.
Available Values: REAR/F+R/FRONT/OFF
Default: REAR
REAR: Outputs the receiving audio from the REAR speaker (located in the transceiver's
body).
F+R: Outputs the receiving audio from both FRONT (located in the front panel) and
REAR speakers.
FRONT: Outputs the receiving audio from the FRONT (located in the front panel) speaker.
OFF: Disable the FRONT and REAR Speakers.
Set Mode Item [
F35 SQL BELLF35 SQL BELL
F35 SQL BELLF35 SQL BELL
F35 SQL BELL]
Function: Selects the number of CTCSS/DCS/EPCS Bell ringer repetitions.
Available Values: OFF/1T/3T/5T/8T/CONT (Continuous ringing)
Default: OFF
Set Mode Item [
F36 SQL DCSF36 SQL DCS
F36 SQL DCSF36 SQL DCS
F36 SQL DCS]
Function: Setting of the DCS code.
Available Values: 104 standard DCS codes
Default: DCS(023)
Set Mode Item [
F37 SQL EXPF37 SQL EXP
F37 SQL EXPF37 SQL EXP
F37 SQL EXP]
Function: Enables/Disables split CTCSS/DCS coding.
Available Values: OFF/ON
Default: OFF
When this Set Mode Item is set to “ON,” you will see the following additional parameters
after the “DCS” parameter while configuring Menu Item “F40 SQL TYPE”.
DCS ENC: DCS Encode only.
TONE DCS: Encodes a CTCSS tone and Decodes a DCS code.
DCS TSQL: Encodes a DCS code and Decodes a CTCSS tone.
Select the desired operating mode from the selections shown above.
Set Mode Item [
F38 SQL LEVLF38 SQL LEVL
F38 SQL LEVLF38 SQL LEVL
F38 SQL LEVL]
Function: Set the squelch threshold level.
Available Values: SQL OFF/SQL MIN/SQL 01/SQL 02/ SQL 03/ SQL 04/ SQL 05/ SQL
06/ SQL MAX
Default: Amateur Bands: SQL 01, AM: SQL 01, FM: SQL 02
