Sylvania HT6051F Portable DVD Player User Manual



22
EN
AV Receiver
DVD/CD Player :
Output signal format:
NTSC color
Power source:
120 V AC +/- 10%,
60 Hz +/- 0.5%
Power consumption:
10 W (standby: 0.8 W)
Operating temperature:
41°F (5°C) to 104°F (40°C)
Dimensions (Vertical installation):
W : 2 1/2" (62 mm)
H : 9 13/16" (249 mm)
D : 9 7/16" (239 mm)
Weight : Approx 2.9 lbs. (1.3 kg)
AV Receiver :
Power source:
120 V AC +/
-
10%,
60 Hz +/- 0.5%
Power consumption:
4 W (standby: 0.9 W)
Operating temperature:
41°F (5°C) to 109°F (40°C)
Dimensions:
W : 2 1/2" (62 mm)
H : 9 13/16" (249 mm)
D : 9 7/16" (239 mm)
Weight : Approx 1.9 lbs. (0.9 kg)
Speaker Unit :
Amplifier
Output Power (8, 1kHz, 10%THD)
100W total
Front Speakers : 12W/ch
Rear Speakers : 12W/ch
Center Speaker: 12W/ch
Subwoofer : 40W/ch (4)
Frequency Response
20Hz - 20kHz
Signal -to- Noise Ratio
80db (One channel driven Sat Power =
10w at 1kHz, WF Power = 30W at
100HZ)
Dimensions (w x h x d)
Front Speakers:
3 15/16" x 7 3/16" x 4 9/16"
100 x 182 x 115 mm
1.8 lbs. (0.8 kg)
Rear Speakers:
12 5/8" x 4 3/16" x 4 9/16"
320 x 105 x 115 mm
3.6 lbs. (1.6 kg)
Center Speaker:
7 1/8" x 4 3/16" x 4 9/16"
180 x 105 x 115 mm
1.6 lbs. (0.7 kg)
Subwoofer:
6 1/8" x 10 1/8" x 12 13/16"
155x 257 x 325 mm
11.5 lbs. (5.2 kg)
NOTE: Designs and specifications are
subject to change without notice.
Specifications
Information
For proper Surround Sound, connect the speakers and Subwoofer correctly. Details are on page 9.
The Center and Rear speakers only operate when Surround is on. The Discs or TV programs must be
recorded or broadcast in Surround Sound.
1
Press [SURROUND] to set Surround to on or off. When Surround is on, the “Surround” will be
displayed on the display of the AV Receiver. When Surround is off, the “Surround” will disappear.
Programs broadcast in Stereo will produce some surround sound effects when played in a surround
mode. However, non-Stereo programs will not have any sound at the Rear speakers.
The following Surround Sound modes may be broadcast by DVDs or TV stations.You cannot alter
these Surround Sound options at the receiver.
Surround Sound Display
Surround Sound
Digital Sound
Digital Sound lets you enjoy special sound effects that have preset equalizer settings, providing the best
music reproduction.
1 Press [SOUND] repeatedly to select ROCK, POPS, CLASSIC, JAZZ or off. The selected Digital
Sound indicator will light up on front of the AV Receiver.
2ch:
Sound Setting
Dolby 2ch: Dolby 5.1ch:
Dolby Pro Logic II: Dolby 2ch Pro Logic II:
Bass Boost
You can emphasize the bass sound.
1 Press [BASS BOOST] to set Bass boost to on or off. When Bass boost is on, the Bass boost indi-
cator will light up on front of the AV Receiver.
