Setup
RF Modulator Connection (If Your TV Does Not Have A/V Input Jacks.)
If your TV has Antenna in jack only, it is still possible to
connect this player to your TV by using a STEREO
AUDIO/VIDEO RF Modulator (commercially available).
In this case, follow the instructions below.
1) Connect the AUDIO/VIDEO output jacks of this player to
the AUDIO/VIDEO input jacks of your RF Modulator by
audio and video cables.
2) The antenna input jack of your TV may have been already
occupied. If so, disconnect the RF cable from your TV, and
then connect the RF cable to your RF Modulator (usually
marked “ANT IN”).
3)
Connect your RF modulator to your TV by another RF cable.
4) Set your RF modulator’s channel 3/4 switch to either 3 or
4, whichever the TV channel is least used in your area. If
your RF modulator has a Modulator/Antenna switch, set it
according to your RF modulator’s manual.
5) Turn on your TV and choose the same channel as you set
the RF modulator’s channel 3/4 switch to. For more details,
follow the instructions supplied with the RF Modulator.
Hint
Hint
The quality of picture may become poor if the player is
connected to an RF Modulator.
AUDIO
OUT
R
L
Y
C
R/PR
CB/PB
VIDEO
OUT
COMPONENT
VIDEO OUT
BUS 2
BUS 1
Stereo Audio/Video RF Modulator
(commercially available)
TO TVCHANNEL VIDEO AUDIO
RL34
ANT IN
AC 120V
(Back of TV)
Audio/Video
Cables
(Supplied)
(Back of the
DVD/CD Player)
RF Cable (Not supplied)
Antenna
Cable
Signal
3
2
1
Antenna in jack
