Sylvania HT6051F Portable DVD Player User Manual



21
EN
AV Receiver
AV Receiver
1 Press [AMP POWER] to turn on the AV Receiver.
2 Press [TUNER] to select Tuner mode. The current radio frequency
(station number) will appear on the display.
3 Press
[REPEAT/BAND] to select FM or AM.
4 Use
[SKIP
HH
HH
/
GG
GG
] to select a preset radio station.
5 Use [TUNING o / p] to change the radio frequency.
6
Press and hold
[TUNING o / p]
for 2 seconds for search
mode. The next available station will be tuned.
Selecting Radio Stations
Hint
Hint
[SKIP
HH
HH
/
GG
GG
] will not function if there
is no preset radio station.
1 Press [AMP POWER] to turn on the AV Receiver.
2 Press [TUNER] to select Tuner mode. The current
radio frequency (station number) will appear on the
display of the AV Receiver.
3 Press
[REPEAT/BAND] to select FM or AM.
4 Use
[TUNING o / p] to select the station you want to preset.
5 Press
[SETUP] for 1 second. Preset number will flash.
6 Use
[SKIP
HH
HH
/
GG
GG
] and select a preset number, then press
[SETUP].
AM / FM Radio
Preset Radio Stations
To Connect AM/FM Antenna
To connect AM Antenna:
Fix the antenna holder as shown.
1
1
Hint
Hint
Do not place the AM antenna on top of the player, the
receiver or the speakers. Keep it as far as possible from
other equipment.
For better FM reception, connect an outdoor FM
antenna (not supplied) to the FM jack (75).
To connect FM Antenna:
Connect the supplied FM antenna to the FM jack
on back of the AV Receiver. Extend the FM
antenna wire and fix its end to the wall.
1
1
Connect the supplied AM antenna to the
AM jack on back of the AV Receiver, then
position it to receive the clearest sound.
2
2
AV Receiver
AV Receiver
AM Antenna
FM Antenna
Hint
Hint
You can store up to 40 preset radio stations.
If you want to delete a preset radio station, use
[SKIP
HH
HH
/
GG
GG
] to select the preset number,
press and hold
[SETUP].When the preset
number flashes, press
[CLEAR].
If the sound is distorted during AM recep-
tion, use [TUNING
oo
/
pp
] on the remote
control to reduce the noise.This is effective
only for the current AM station.This does
not work for every situation.There may be
interference from other electrical appliance
or weak AM signals.
