5
C. WEATHER CENTER
1. Remove the battery cover.
To do this, place a solid
object in the space
provided at the lower-
central position of the
battery cover (the cover
has white writing on it)
then push up and pull out
on the battery cover.
2. Observe the correct
polarity, and install three
AA batteries.
3. Replace the battery cover.
THE LCD SCREEN
Immediately after the batteries have been installed, the LCD (Liquid Crystal
Display) Screen will completely light up for a brief moment.
Note:
After the LCD Screen briefly lights up, “375” will appear at the top of the
LCD, then the LCD will display the default settings. There is also a satellite icon
that appears between the Outdoor temperature and humidity—this icon informs
the user that the Weather Center is receiving signals from the sensors. Within 12
minutes the Outdoor temperature and humidity should be displayed—if not,
remove batteries from all units and repeat battery installation.
Following is a general display description of the LCD layout. Details
concerning the LCD Screen will be
explained during the complete
Programming sections and the Features
& Operations sections.
LCD 1—shows the time.
LCD 2—indoor temperature/humidity.
LCD 3—forecast icons and air pressure.
LCD 4—rainfall/air pressure histories,
and rain quantity.
LCD 5—air pressure and rain quantity
LCD 6—outdoor temperature/humidity.
Battery Cover
Removable Table
Stand
Hanging Hole
LCD 1
LCD 2
LCD 3
LCD 4
LCD 5
LCD 6
