MAINTENANCE AND CARE
Extreme temperatures, vibrations, and shock should be avoided to prevent
damage to the units.
Clean displays and units with a soft, damp cloth. Do not use solvents or
scouring agents—they may mark and damage the displays and casings.
Do not submerge in water.
Immediately remove all low powered batteries to avoid leakage and
damage. Replace with new batteries only, and of recommended size.
Opening the casings invalidates the warranty. Do not try to repair the units.
Contact La Crosse Technology for Repairs.
TROUBLESHOOTING
Problem:
The LCD is faint.
Solution:
1) Set the LCD contrast to a higher level.
2) Replace batteries.
Problem:
No outdoor temperature/humidity or rainfall is displayed.
Solution:
1) Remove all batteries, reinsert into sensor first, then Weather
Center.
2) Place remote sender closer to display.
3) Be sure all batteries are fresh.
4) No other interfering sources on a 433MHz frequency are
being used (such as computer monitors, TV sets, headphones,
or speakers) in the vicinity.
5) Transmission may have limited capabilities.
6) Perform Hard Reset in section VI, C.
Problem:
Need to reset the bar graph (EEPROM Weather Center memory).
Solution:
1) Remove batteries, and follow instructions in VI, C under
Features and Operations.
Problem:
Rainfall amount is not correct.
Solution:
1) Manually change the rain multiplicator number to 375,
following instructions in VI, B
Problem:
Temperature/Humidity are incorrect.
Solution:
1) Check/Replace batteries.
2) If multiple sensors are in use, check location with
corresponding “boxed numbers.”
3) Move away from sources of heat/cold.
Problem:
“- -” in humidity display.
Solution:
1) Humidity is below 20% or above 95%.
2) TX3U or TX3UP is used.
Problem:
Air pressure is incorrect.
Solution:
1) Adjust relative air pressure to a value from a reliable source
(TV radio, etc.).
SPECIFICATIONS
