35
English
Owner’s manual
36
English
Owner’s manual
(2-3) Color
To adjust the color depth.
If you touch the [ - ] key, the color depth will decrease.
If you touch the [ + ] key, the color depth will increase.
(2-4) Hue
If you touch the [ R ] key, red is emphasized.
If you touch the [ G ] key, green is emphasized.
Only NTSC, it can setup.
(3) Adjusting the GENERAL
(3-1) Default Screen
Press the [ADJ] button, then touch the [GENERAL] key.
Perform the adjustment.
Touch the [BACK] key to return to the previous screen.
GENERAL DEFAULT SETTING RANGE
BEEP ON ON or OFF
AUTO PANEL ON ON or OFF or CLOSE
TEL SWITCH OFF ON or OFF or MUTE
TEL SPEAKER RIGHT LEFT or RIGHT
(3-2) CLOCK
Touch the [ADJUST] key to set up the time.
Touch the [AM] or [PM] key.
Touch the [ - ] or [ + ] key to change the time.
(3-3) BEEP
When pressing Button or Key, Beep Sounds
To turn on/off Beep, touch the [ON] or [OFF] key.
In spite of “OFF” setting, the Warning sound comes out.
When memorizing, Beep sounds longer.
[AUTO] : According to the status of the car light, brightness of LCP is changed.
(When the car light is off : Day color, when the car light is on : Night color, Only
“NIGHT” setting can control the dimmer level by touching the [ - ] or [ + ] key.)
(1-3) CAMERA INT.
Touch the [ON] key to turn rear camera on when reverse line is activated.
Touch the [OFF] key to ignore reverse line not to be interrupted by camera.
(1-4) CAMERA WARNING
When you are using CCD camera, touch the [ON] key if you want to see the warning message
or touch the [OFF] key if you do not want to.
(1-5) NTSC/PAL/AUTO
To set the VTR system for AUX video input. When selecting AUTO mode, monitor will
automatically be selected the video system according to input video signal.
(2) Adjusting the MONITOR : At AUX, DVD Mode
(2-1) Brightness
Touch the [ADJUST] key to adjust brightness for display image.
Touch the [ - ] key and screen becomes dark
Touch the [ +] key and screen becomes bright
(2-2) Dimmer
Touch the [ADJUST] key to adjust the brightness of LCP when the car lights are on/off.
[DAY] : Brightness of LCP is always set to maximum level.
[NIGHT] : Brightness of LCP is always set to user setting level in adjust mode.
[AUTO] : According to the status of the car light, brightness of LCP is changed.
(When the car light is off : DAY color, when the car light is on : NIGHT color)
Only "NIGHT" setting can control the dimmer level by touching the [-] or [+] key.
