(3) Adjusting the angle of the LCP
Every pressing the [OPEN] button more than a second tilts LCP forward or backward.
The angle is changed the following order:
110°(Default angle) 100° 90° 80° 70° 80° 90° 100° 110°
If the LCP stops in error during the adjustment of the angle and you press the [OPEN] button
more than a second, the LCP operates With opposition direction.
The adjusted angle is stored in memory. There are 5 adjustable angles available within the
range 70° to 110°.
(4) Housing the LCP
Press the [OPEN] button and the LCP is automatically housed. If you do not use the unit for a
long time or leave the car, please house the LCP.
7-2-4 AUDIO Operations
Z-ENHANCER
BASS BOOST
IMPACT
EXCITE
CUSTOM DETAIL
SUB WOOFER VOL
M-B EX
HIGH PASS FILTER
LOW PASS FILTER
AMP CANCEL
SOUND
BAL/FAD
Z-ENHANCER
OTHERS
BASS GAIN
BASS FREQ
BASS Q
TREBLE GAIN
TREBLE FREQ
Open or Close function might not be working properly if ACC is off while opening or closing LCP or
LCP is moved by manually.
7-2-2 MODE Selections
(1) When the LCP is open
Press the [SOURCE] button to enter in the SOUCRE mode.
Touch the desirable key.
(2) When the LCP is closed
Press the [SOURCE] button to change operation mode.
Each time you press the [SOURCE] button, the operation mode changes in the following order:
TUNER mode DVD/CD Play mode USB mode or iPod mode AUX mode
When 2ZONE function is ON, the [SOURCE] button operates only for the MAIN zone.
To switch to a SUB zone source, specify from the Source menu screen, or use the remote
control unit.
7-2-3 LCP Operations
(1) Cautions
To prevent the battery from going dead, operate this unit with the engine running if possible.
When the liquid crystal panel is operating, be careful not to get your hand or finger caught
between the panel and main unit or the instrument panel of the care. Do not move the liquid
crystal panel by hand.
(2) Standing up the LCP
Press the [OPEN] button. The LCP comes out and stands up automatically. The power of this
unit will be turned on.
Press the [OPEN] button to house LCP and press the button again to
raise it, if the LCP stops in the middle of its operation. The unit will enter the same display
mode as the display was in when last turned off.
