Owner’s manual
31
English
Owner’s manual
EXCITE - detail adjustments
SET BASS TREBLE
+3 F = 50Hz, G=+ 10dB, Q=1 F=12KHz, G= +8dB
+2 F = 50Hz, G=+ 8dB, Q=1 F=12KHz, G= +8dB
+1 F = 50Hz, G=+ 8dB, Q=1 F=12KHz, G= +6dB
0 F = 50Hz, G=+ 6dB, Q=1 F=12KHz, G= +6dB
-1 F = 50Hz, G=+ 6dB, Q=1 F=12KHz, G= +4dB
-2 F = 50Hz, G=+ 4dB, Q=1 F=12KHz, G= +4dB
-3 F = 50Hz, G=+ 4dB, Q=1 F=12KHz, G= +2dB
IMPACT - detail adjustments
SET BASS TREBLE
+3 F = 80Hz, G=+10dB, Q=1 F=8KHz, G= +6dB
+2 F = 80Hz, G=+ 8dB, Q=1 F=8KHz, G= +6dB
+1 F = 80Hz, G=+ 8dB, Q=1 F=8KHz, G= +4dB
0 F = 80Hz, G=+ 6dB, Q=1 F=8KHz, G= +4dB
-1 F = 80Hz, G=+ 6dB, Q=1 F=8KHz, G= +2dB
-2 F = 80Hz, G=+ 4dB, Q=1 F=8KHz, G= +2dB
-3 F = 80Hz, G=+ 4dB, Q=1 F=8KHz, G= 0dB
Custom Setting
: Touch the [CUSTOM] key and then touch the [CUSTOM DETAIL] key.
BASS controls low sound, TREBLE controls high sound.
CUSTOM DETAIL DEFAULT SETTING RANGE
BASS GAIN 0 -6 ~ +8
BASS FREQ 50Hz 50Hz or 80Hz or 120Hz
BASS Q 1 1 or 1.25 or 1.5 or 2
TREBLE GAIN 0 -6 ~ +6
TREBLE FREQ 12KHz 8KHz or 12KHz
BASS BOOST, IMPACT, EXCITE Setting
: Select favorite setting mode from these presets and touch respective the [ - ] or [ + ] keys to
adjust the level.
“BASS BOOST” emphasizes low sound.
“IMPACT” emphasizes both low sound and high sound.
“EXCITE” weakens intermediate sound and emphasizes both low sound and high sound.
BASS BOOST - detail adjustments
SET BASS TREBLE
+3 F = 80Hz, G=+12dB, Q=1 F=12KHz, G= 4dB
+2 F = 80Hz, G=+10dB, Q=1 F=12KHz, G= 4dB
+1 F = 80Hz, G=+ 8dB, Q=1 F=12KHz, G= 4dB
0 F = 80Hz, G=+ 6dB, Q=1 F=12KHz, G= 4dB
-1 F = 80Hz, G=+ 4dB, Q=1 F=12KHz, G= 4dB
-2 F = 80Hz, G=+ 2dB, Q=1 F=12KHz, G= 4dB
-3 F = 80Hz, G=+ 0dB, Q=1 F=12KHz, G= 4dB
(1) Adjusting the Z-ENHANCER
Press the [SOUND] button. (This button performs only when the panel is open.)
Touch the desirable item key(Z-ENHANCER, BAL/FAD, OTHERS).
Perform the adjustment explaining in the following sections.
Touch the [BACK] key to return to the previous screen.
ITEM DEFAULT SETTING RANGE
Z-ENHANCER OFF ON or OFF
BASS BOOST 0 -3 ~ +3
IMPACT 0 -3 ~ +3
EXCITE 0 -3 ~ +3
