Owner’s manual
13
English
Owner’s manual
Inserting the Batteries
Open the rear cover, and remove it and insert the AAA (SUM-4, IEC LR03/1.5V) batteries bundled
with the remote control unit in the directions shown in the figure and then, close the rear cover.
Using batteries improperly can cause them to explode. Take note of the following points:
• When replacing batteries, replace both batteries with new ones
• Do not short-circuit, disassemble or heat batteries.
• Do not dispose batteries into fire or flames.
• Dispose of spent batteries properly.
Button Functions
You can use the remote control unit to control this unit. The steering wheel remote control operation
work on the MAIN zone even when the SUB zone is selected.
[PWR/SRC] : To turn on/off the power (press this button more than 2 seconds)
To switch the modes
[BAND] : To switch reception band in TUNER mode
[RPT] : To repeat chapter in DVD mode or repeat track in CD/MP3 modes
To perform folder repeat in MP3 mode
[SCAN] : To scan tracks in USB mode
To scan chapters in DVD mode and tracks in CD/MP3 modes
To scan folders in MP3 mode (keep pressing more than a second)
[RDM] : To play tracks at random in CD/MP3 modes
To play folders at random in MP3 mode (keep pressing more than a second)
[PBC] : To turn on/off PBC function in the Video CD mode
[0-9] : To select the preset number in the Preset List screen of the TUNER mode
To input number of key pad screen in DVD mode
Rear side
Battery cover
AAA (SUM-4, IEC LR03/1.5V)
Batteries
3-2 Remote Control
Remote Control Unit (38 buttons)
PWR/SRC BAND
RPT
SCAN
RDM
PBC
SETUP
ENTER
RTN TOP MENU
SLOW
P.CH
VOLUME
AUDIO SUB TITLE
WIRELESS REMOTE CONTROLLER
ANGLE 2-ZONE
PLAY/PAUSE
MUTE
MENU
P.TIME
SEARCH MODE
PWR/SRC
RPT
SCAN
RDM
PBC
SETUP
RTN
SLOW
P.CH
AUDIO
SUB TITLE
BAND
0 ~ 9
P.TIME
SEARCH MODE
MENU
ENTER
TOP MENU
MUTE
PLAY/PAUSE
VOLUME
2-ZONE
ANGLE
