A • Specifications Model 4520 & 4110 Series Getting Started Guide
58 Management
IPSEC AH & ESP Modes
Manual Key; IKE optional
AES/DES/3DES Encryption
Management
Industry standard CLI with local console (CRJ-45, RS-232) and remote Telnet access
TFTP configuration & firmware loading
SNMP v1 agent (MIB II and private MIB)
Built-in diagnostic tools (trace, debug)
Java™ Applet; HPOV Integration with NNM
Operating Environment
Operating temperature
32–104°F (0–40°C)
Operating humidity
5–80% (non condensing)
System
CPU Motorola MPC859 operating at 50 MHz
Memory:
32 Mbytes SDRAM
4 Mbytes Flash
Compliance
EMC compliance: EN55022 and EN55024
Safety compliance: EN 50950
CE compliance
FCC Part 15 Class A
Dimensions
7.3W x 1.6H x 6.1D in. (18.5H x 4.1W x 15.5D cm)
