62 HP StorageWorks Disk Arrays XP128/XP1024: Owner’s Guide
9 BS ON LED
(Yellow)
When the LED is on, unit is plugged in and receiving
power from the primary AC outlet. The SVP is
receiving power from the outlet.
If BS is off, then the disk array is not receiving power
from the primary AC outlet. Check the electrical
outlets in your building.
10 PS ON LED
(Green)
When the LED is on power switch is on, the array is
ready to receive data.
Off means the power switch is off; the disk array is not
powered on and is not ready to receive data.
11 PWR SW ENABLE Switch Used to enable the PWR on/off switch. To enable the
PWR on/off switch, turn the PWR SW ENABLE
switch to the ENABLE position. If the automatic
power on restart feature is not being used, this switch
should be in the DISABLE (opposite of ENABLE)
position during normal operation.
12 PWR ON/PWR OFF Switch To switch on/off the subsystem, use this switch while
turning the PWR SW ENABLE switch is in the
ENABLE position. This switch only performs this
function when the REMOTE/LOCAL switch is set to
the LOCAL position.This switch should be in the
PWR ON position during normal operation. The
position of this switch should only be changed when
directed by HP service personnel.
13 EMERGENCY POWER
OFF
Switch Used to power off the storage subsystem in an
emergency situation.
Table 11. Control panel functions
Item Label Indicator Description
