XP128 Hardware 43
Specifications
Some of the HP StorageWorks Disk Array XP128 disk array specifications
are listed in this section. For a complete set of environmental specifications,
refer to the
HP Disk Array XP128 Site Prep Guide on the following main
web site and access the appropriate support product:
http://www.hp.com
Temperature
Table 3. Temperature Specifications
Humidity
Table 4. Humidity Specifications
Mechanical vibration
Table 5. Mechanical vibration
Temperature Specification (Degrees F = 1.8 x Degrees C + 32)
Nonoperating temperature Range
–10
° to +43° C
Operating Temperature
+16
° to + 32° C
Recommended Operating Temperature Range
+21
° to +24° C
Shipping and storage temperature
–25
° to 60° C
Temperature Shock Immunity—Maximum rate of
change
10
° C per hour
Over-Temperature shutdown
Shutdown at 60
° C
Humidity Specification
Nonoperating/storage Humidity Range 8% to 90% RH
Operating Humidity Range at 22
° C
20% to 80 % RH
Recommended Operating Humidity Range at 22
° C
50% to 55 % RH
Procedure for recovery from moisture condensation None
Mechanical vibration
Maximum Operating
Acceleration
0.05G at a frequency range of 10 to 300 Hz
