Specifications
18
Item Part Number Description Qty
53 90038-053 Engine 1
54 90038-054 Valve Handle Connector 1
55 90038-055 Bolt M8x45 3
56 90038-056 Plate 1
57 90038-057 Lock Nut M8 7
58 90038-058 Lock Washer ø12 12
59 90038-059 Outlet Pump Connector 1
60 90038-060 Oil Pipe 1
61 90038-061 O-Ring 2
62 90038-062 Front Support Leg 1
63 90038-063 Gear Pump Connector 1
64 90038-064 Gear Pump Stand 1
65 90038-065 Engine Connector 1
66 90038-066 Engine Bushing 1
67 90038-067 Lock Nut M12 7
68 90038-068 Big Flat Washer ø12 2
69 90038-069 Filter Fix Plate 1
70 90038-070 Rubber Washer 2
71 90038-071 Filter 1
72 90038-072 Fender 2
73 90038-073 Bolt M10x30 6
74 90038-074 Flat Washer ø20 2
75 90038-075 Hex Bolt M6x20 6
76 90038-076 Lock Washer ø6 6
77 90038-077 Flat Washer ø6 6
78 90038-078 Clamp 2
79 90038-079 Screw M6x10 1
80 90038-080 Key 1
81 90038-081 Flat Key 1
82 90038-082 Oil Cap Bushing 1
83 90038-083 Sponge 1
84 90038-084 Oil Cap 1
85 90038-085 Screw M4x12 1
86 90038-086 Lock Nut M4 1
87 90038-087 Lock Washer ø4 1
88 90038-088 Flat Washer ø4 1
89 90038-089 Adjustable Washer
90 90038-090 Bolt M8x30 4
91 90038-091 Nut 1
92 90038-092 Valve B, Connector 1
93 90038-093 O Ring 1
94 90038-094 Front Cover Connector 1
95 90038-095 Connection Flange 1
96 90038-096 Bolt M8x25 4
97 90038-097 Flat Washer ø10 11
98 90038-098 Oil Cup M6 2
99 90038-099 Axle, Inner Bushing 2
100 90038-100 Washer ø10 4
101 90038-101 Polyurethane Block 4
102 90038-102 Pin 5x22 1
103 90038-103 Handwheel 1
104 90038-104 Oil Indicator 1
105 90038-105 Oil Plug 1
106 90038-106 Tapping Screw 4
